The components are glued to the case with hot silicone. It would be convenient when soldering to use Flux "Solder Paste" to clean and improve the soldering. In the photos I leave you can see well how it is soldered. The soldering is simple, just join the positive poles with the red wire and the negative poles with the black wire. The lithophany is in color with an A4 size printed foil that I include in PDF to paste on the back to backlight the colors.įor more information and models I leave the link to Instagram where we post everything we do: It has 1500mah battery and RF remote control to control the intensity and other functions, also has a small hole to put a socket and hang on the wall.
You need, 50cm of 10mm thick cool white 5v cool white led strip with RF controller and remote control, a lithium battery and a mini charging electronics with micro-USB C connector, I leave the links below, the battery can be of more capacity as long as the size is not too big and not more than 10mm wide.
The tools you need are: a silicone gun, a soldering iron and tin. The 2 pieces are printed on the 3d printer, then the PDF is printed and the drawing is cut out to paste it behind the lithophany, then the electronics are put into the box which is then glued to the lithophany using cyanoacrylate carefully to leave it centered. For this model you must have basic notions of electronics, mainly soldering with tin, it is composed of 2 pieces and a print on A4 sheet, 1st the box and 2nd the lithophane.
